Architecture

info

This page covers the internal architecture of Flow Control including data flow, tech stack, and key architectural decisions.

Flow Control series

1. Flow Control
2. Architecture - You are here
3. Cursor sync daemon
4. Music sync daemon
5. Health sync daemon (disabled)
6. HealthSync iOS app
7. Deployment

Data flow overview

Tech stack

Component	Technology
Framework	Next.js 15 (App Router)
Database	PostgreSQL 16
ORM	Prisma 7 with @prisma/adapter-pg
Authentication	Auth.js v5 + OIDC provider
Charts	Recharts
UI	Tailwind CSS, Radix UI
Deployment	Kubernetes + Flux GitOps

Database schema

The dashboard uses several key tables:

CursorEvent

Stores individual Cursor AI usage events.

Column	Type	Description
eventDate	DateTime	Timestamp of request
kind	String	Request type (Included, On-Demand)
model	String	AI model used
inputTokens	Int	Input tokens
outputTokens	Int	Output tokens
cost	Decimal	USD cost

DailyStat

Pre-computed daily statistics for fast rendering.

Column	Type	Description
date	Date	Primary key
cursorRequests	Int	Daily request count
cursorCost	Decimal	Daily cost
pipelineTotal	Int	Total pipelines
firstActivity	Time	First activity time
lastActivity	Time	Last activity time

DailySleep

Sleep records from Apple Health.

Column	Type	Description
date	DateTime	Sleep date (wake-up date convention, matching Oura)
sleepStart	String	Sleep start time (HH:MM)
sleepEnd	String	Sleep end time (HH:MM)
timeAsleepMins	Int	Actual sleep minutes
efficiency	Int	Sleep efficiency (0-100)
remMins	Int	REM stage duration
coreMins	Int	Light/Core stage duration
deepMins	Int	Deep stage duration
importedAt	DateTime	When the record was first created
rollingDebtMins	Int?	Unused -- snapshotting was tried and removed (see decisions below)

Workout

Workout sessions from Apple Health (via HealthSync iOS). Includes distance (Decimal, km) from HKWorkout.totalDistance for running, cycling, walking.

MusicEvent

Music listening events from the music-sync daemon.

Column	Type	Description
trackName	String	Track title
artist	String	Track artist
album	String	Album name
genre	String?	Genre tag
duration	Float?	Track duration in seconds
startedAt	DateTime	When playback started
endedAt	DateTime?	When playback ended/changed

HealthSettings

Configuration and cached AI insights.

Column	Type	Description
sleepDebtThreshold	Int	Daily sleep target in minutes (default 450 min / 7.5h). Configurable from the iOS app's Sleep Preferences.
sleepDebtWindow	Int	Rolling window (default 14 days)
cachedInsight	Json?	Cached AI health insight
cachedInsightAt	DateTime?	When insight was cached

Key architectural decisions

Production-only environment

Decision: Single production environment, no dev/staging.

Why:

1. Simplicity reduces maintenance overhead
2. Personal dashboard does not need multiple environments
3. GitOps makes rollbacks trivial if needed

Local daemons for locked data

Decision: Run daemons locally on Mac rather than in Kubernetes.

Why:

1. Cursor stores auth token in local SQLite (cannot access from cluster)
2. Health data flows through local Google Drive sync
3. Daemons have minimal resource requirements

Auto-discovery of GitLab projects

Decision: Dynamically discover projects from GitLab API instead of hardcoded list.

Why:

1. New projects automatically tracked without code changes
2. No manual configuration when adding repositories
3. Projects refreshed on each import cycle

Gap-aware active hours

Decision: Calculate active hours by detecting gaps greater than 30 minutes.

Why:

1. Span hours (first to last activity) overstate work time
2. Breaks for meals, meetings, and sleep should not count
3. More accurate representation of actual work

AI insight caching

Decision: Cache AI-generated health insights until new data arrives.

Why:

1. Health data only updates once per day
2. Reduces AI API costs significantly
3. Faster page loads (cached response is instant)

Billing cycle alignment

Decision: Align all cost displays to Cursor's actual billing cycle.

Why:

1. Dashboard costs must match Cursor's billing page
2. Billing anchor time discovered via API analysis (not always midnight)
3. Users can navigate between billing periods

Sleep debt always computed live

Decision: Compute rolling sleep debt from raw records on every request rather than storing snapshots.

Why:

1. rollingDebtMins snapshots were tried (column exists in DailySleep) but produced wildly incorrect values during bulk imports (e.g., 57 mins stored vs 700 mins computed live)
2. With a single trusted source (Oura via HealthKit), retroactive chart changes from data revisions are minimal
3. Live computation from 28 days of records is fast enough for every page load
4. Eliminates a category of bugs where snapshots and reality diverge

Single-source sleep data

Decision: The iOS app filters HealthKit sleep queries to a single selected tracker (Oura, Apple Watch, iPhone, or AutoSleep).

Why:

1. Multiple sleep sources in HealthKit produce overlapping/duplicate data
2. Combining sources inflated sleep durations by up to 2x, corrupting sleep debt calculations
3. Matching Oura's convention (wake-up date attribution) requires knowing which source is authoritative

Wake-up date convention

Decision: Sleep sessions are attributed to the date you wake up, not the date you fell asleep.

Why:

1. Matches Oura's date convention (the authoritative sleep data source)
2. "Last night's sleep" for Feb 15 is the sleep session ending on Feb 15, even if bedtime was Feb 14
3. Session-based grouping in HealthKitManager.swift uses groupIntoSessions() to cluster samples by a 2-hour gap threshold, then assigns the wake-up date

Minute truncation fix (Feb 15, 2026)

Decision: Accumulate total seconds across all merged sleep intervals per stage, then round to minutes once at the end.

Why:

1. The original mergedMinutes() function floor-truncated (Int()) on each individual interval
2. With 5-20 intervals per stage, each losing ~0.5 min on average, this lost ~13 min/night
3. Over 14 nights, the truncation error accumulated to 3 hours of phantom sleep debt
4. Discovered by comparing Oura native values against the database: consistent ~13 min/night shortfall

API endpoints

Endpoint	Method	Description
/api/health	GET	Health check for K8s probes
/api/sources	GET	Data source status and health
/api/insights	GET	Decision support insights
/api/stats/summary	GET	Aggregated stats for MCP tools
/api/stats/activity-trend	GET	Billing-cycle activity data
/api/stats/forecast	GET	Usage forecasting
/api/health/summary	GET	Health metrics summary
/api/health/insights	GET	AI-powered health recommendations
/api/import/cursor-events	POST	Receive events from daemon
/api/import/music-events	POST	Receive music events from daemon
/api/import/health-app	POST	Receive health data from HealthSync iOS app
/api/import/health	POST	Receive health data from daemon (disabled)
/api/import/gitlab	POST	Trigger GitLab import
/api/music/timeline	GET	Music events for a time range
/api/music/top-flow	GET	Top songs during flow-building periods

Security considerations

Control	Implementation
API key authentication	Bearer token for daemon endpoints
Input validation	Zod schemas for all incoming data
Rate limiting	120 requests/minute per client
Secure token handling	Cursor token read-only, never logged
HTTPS enforcement	Warning logged for non-HTTPS

---

Next: Cursor sync daemon covers the local daemon that fetches Cursor AI usage data. See also Music sync daemon for Apple Music integration.
